Description
Specifications/ Technical Details
| Item Type | LED Driver |
|---|---|
| Shell Material | Plastic |
| Input Voltage | 100V-240V |
| Input Frequency Range | 47-63Hz |
| Output Voltage | 12V |
| Dimmable | No |
| IP Rating | IP44 |
| Waterproof Rating | Non-Waterproof |
s for Led Driver Transformer 12V:
- The power supply accepts input voltages of 100-240V AC providing a constant voltage output of 12V and current of 0.58A.
- Made from engineered plastic material, it ensures durability and longevity this transformer features a compact and lightweight design.
- Install the transformer using screws for walls to ensure fit, and use stickers for smooth surfaces for easy mounting.
- Smart device surge protection for circuit shortage overload and over-voltage the power supply is safe and environmentally protected.
- The power supply lighting transformer is suitable for Strip Light GU4 G4 MR11 and MR16 LED bulbs.
Refer to the table for detailed technical information.
(Power: 7w to 60w, Amp: 0.58A to 5A, AC 90-240V)
|
Power |
Input Voltage |
Output Current |
Length |
Width |
Height |
No of output (in pairs) |
Weight |
|
7W |
100-240V |
0.58A |
99mm |
29mm |
22mm |
1 |
50g |
|
15W |
90-240V |
1.25A |
99mm |
29mm |
22mm |
1 |
65g |
|
35W |
90-240V |
2.9A |
144mm |
44mm |
22mm |
1 |
125g |
|
60W |
90-240V |
5A |
175mm |
42mm |
25mm |
1 |
175g |
Note:
- Always choose a power supply that is at least 25% higher than the required wattage. For example, if your LED strip requires 75w, you should use a 100w or above transformer.
- It is always advisable to seek the help of an electrically competent person if you are not familiar with electricity or electrical systems.
