Description
The SP901E is a compact, high‑performance LED pixel signal amplifier (sometimes called a repeater or buffer). It refreshes and boosts weakened SPI data so you can extend pixel runs, split a controller’s output into multiple branches, or drive mixed‑voltage pixels from the same controller. Thanks to its wide 5–24 V operating range and on‑board reverse‑polarity protection, the SP901E slots straight into new or existing installations and keeps them running reliably.
Inside you’ll find eight fully‑independent single‑signal outputs or four fault‑tolerant dual‑signal outputs (selectable automatically). That means you can take one pixel‑controller port and fan it out to eight 5 V WS2812B strips or four dual‑line WS2813/WS2815 strips, keeping the data voltage identical to your pixel voltage for rock‑solid integrity. Multiple amplifiers can be cascaded to cover very large projects.
-
Pixel Controllers: K‑8000C SPI Master, Micro Pixel YCP Controller
-
Pixel LED Strips: Pixel 60 5 V LED Strip and other WS281x/SK6812 ranges
-
Power Supplies: Choose a constant‑voltage unit to match your pixel voltage,
e.g. 60 W 5 V MeanWell LPV‑100‑5 or browse the 5 V PSU collection
For outdoor installations, mount the amplifier inside an IP‑rated enclosure.
Need help specifying your project? Email [email protected] or call 0113 252 4706 (opt 2) and we’ll be happy to assist.
